Glass and Plastic Bottle Syrup Oral Liquid Filling Capping Machine

Glass and Plastic Bottle Syrup Oral Liquid Filling Capping Machine

Type: Washing Filling Capping Monoblock Liquid Filling Machine
Product Name：High Accuracy Automatic Oral Liquid Filling Machine
Production Capacity：40-800 BPM
Brand: HUIHENG PHARMA
Model: SHH-KF4

Oral Syrup Filling Machine Oral Liquid Bottle Washing Drying Filling Capping Machine Production Line

Product Description

Pharmaceutical Vial Bottle Syrup Washing filling capping Machine

The syrup filling line is composed of four equipments: bottle unscrambler, bottle washing machine, tunnel sterilization oven, and syrup liquid filling & capping machine.
Each equipment can also working independently; It can automatically complete bottle unscrambling, cleaning, pre-heating, sterilization, drying, cooling, filling, screw (rolling) capping and other processes and is suitable for syrups, tinctures, wines, health products, beverages, sauces and other liquids with different viscosity in the pharmaceutical and food industries packaging line production;

Performance Features:

The design, materials, manufacturing, assembly, installation etc of the whole syrup filling line are in line with GMP standard
The syrup filling production line adopts advanced design, reasonable structure, high degree of automation and with stable and reliable operation, high capacity to realizes electric mechanical integration;
The whole production line has strong versatility and need few operators;
Imported variable control program, easy to operate
Filling accuracy, defoaming and not drip
No bottle no filling, no cap no capping
Easy capping design, low bottle breakage rate
Frequency stepless speed regulation
Filling with no pollution, long use life

Pharmaceutical syrup filling machine:

* Applications: 10ml-500ml glass /plastic bottles (according to user specifications);
* Capacity up to 2000-24000 bph;
* Filling head: 1-24 pcs, choose according to capacity;
* Various types of filling pump options: glass pump, metal pump, peristaltic pump, ceramic pump;
* Filling accuracy: ≤±1% (according to the characteristics of the medicine);
* Product pass rate: ≥99%;
* Simple adjustment of operating data, high-precision filling, and easy to use;

Teachnical Parameters:

Product model	SHH-KF2	SHH-KF4	SHH-KF6	SHH-KF8	SHH-KF10	SHH-KF12	SHH-KF16	SHH-KF20
Suitable size(ml)	2-30(vials)
Output(pcs/min)	20-60	40-120	60-200	100-250	120-300	150-400	200-500	280-600
Filling heads	2	4	6	8	10	12	16	20
Power supply	380V 50HZ
Power capacity(KW)	79	79	90	92	108	108	115	132
Total weight(kg)	8500	8500	8800	9300	9900	10200	10800	11800
